Model: CNG215E & CNG215H
Body Material: Stainless Steel
Sensor Type: Hall sensor
Working pressure: 0-200bar
Testing pressure: 0-400bar
Accuracy:1.6% F.S.
Working temperature:-40~120℃
| Specification | Body Material | Stainless steel |
| Over Pressure | 520*30 min | |
| Burst Pressure | >1000bar | |
| Testing Pressure | 0-400bar | |
| Working Pressure | 0-200bar | |
| Leakage Rate | <1> | |
| Accuracy | 1.6% F.S | |
| Working temperature | -40~120℃ | |
| Durability | >80,000 cycles | |
| Thread | 1/4"BSP, M14*1.5, M12*1.5 | |
| Certification | ECE-R110 | |
| Waterproof | IP65 |
