Model: PS0-N
Sensor Type: MEMS
Pressure Range: 0/1 bar ~0/10bar (absolute pressure)
Accuracy: 1.0%(0.5% available)
Protection: IP67
PS0 series is a MEMS type sensor for gas, such as atmosphere, oxygen, CNG, LPG, LNG, etc.
Advantages: small volume, light weight, low power consumption, high reliability, high sensitivity,high durability(upto 1 million cycles).
Specification | Sensor type | MEMS |
Body material | SS304, SS316, SS316L, Brass, Aluminium | |
Pressure range | 0/1 bar ~0/10bar (absolute pressure) | |
Default connector | N3 (mate with AMP2-967642-1, can choose N, M, E) | |
Thread size | M12x1.25(can choose B4, B8, N4, N8) | |
Pressure response time | 5ms | |
Burst pressure | 2X Absolute pressure | |
Working temperature | -40~120℃ | |
Accuracy | 1.0%(0.5% available) | |
Protection | IP67 | |
Temperature compensation | Yes |
