Model: LB917H
Size: 50mm
Case Material: Stainless steel, Polished
Pressure Range: 0~700bar, 0~1000bar
Accuracy: Mechanical:1.6%/1.0%, Electrical: 1.0%/0.6%
LB917 are pressure gauge with linear volt output(for hydrogen energy), A sensor is inside the gauge to supply output.
It can be customized, the advantages of Reliability, Visibility, and Precision. It can fully meet the requirements of the application of automobile and industry.
| Specification | Case & Ring | Stainless steel, Polished |
| Window | Polycarbonate | |
| Dial | Plastic | |
| Pointer | PA66+30%GF | |
| Connection | Stainless steel | |
| Movement | Brass, Stainless steel | |
| Bourdon Tube | Stainless steel | |
| Thread size | 1/4''BSP, M10x1 Female | |
| Protection | IP67 | |
| Pressure range | 0~700bar, 0~1000bar | |
| Accuracy | Mechanical: 1.6%/1.0%* Electrical: 1.0%/0.6%*(*Available) |
What is a loose joint?
When installing the pressure gauge, you can adjust the orientation of the gauge freely according to your needs, which will be more convenient for reading data and maintaining, or other purposes.
