Body: SS304
Filling Liquid: No filled
Pressure Range: VAC~0.6bar~1000bar
Accuracy: Mechanical: 1.6%/1.0%* Electrical: 1.0%/0.6%* (*Available )
Input: 5v(default) / 6~36v
Output: 0.5~4.5v(default) / Customized
Size: 50mm、63mm、100mm(Other available）
It’s linear volt output, the output is based on a mechanical system with extra compensation.
Application: Corrosive atmospheres, vibration and pulsation environments, food industry, water suppliers, medical.
Specification | Diameter | B:50mm |
Filling Liquid | No filled | |
Case & Ring | SS304, Polished | |
Mount Type | Bottom Mount | |
Window | Polycarbonate | |
Dial | Plastic | |
Pointer | PA66+30%GF | |
Connection | Brass NPT/BSP/BSPT/Metric | |
Movement | Brass | |
Bourdon Tube | Phosphorus Bronze | |
Protection | IP67 | |
Pressure range | VAC~9PSI~15000PSI | |
Accuracy | Mechanical: 1.6%/1.0%* Electrical: 1.0%/0.6%* (*Available ) | |
Advantages | Reliability, visibility, precision |
